1 工作台面积 Area of working table (W×L) 150×630mm 2 工作台**大纵向行程 Max.longitudinal travel of the table 350mm 3 工作台**大横向行程 Max.cross travel of the table 145mm 4 T槽宽度 Width of T slot 12mm 5 主轴锥孔 Spindle laper hole MT3 6 主轴套筒移动**大距离 Max.quill movement of spindle 80mm 7 主轴中心线至立柱面距离 Distance between spindle center to column surface 165mm 8 主轴箱水平回转角度 Max.vertical rotation of spindle box around column ±180° 9 主轴箱垂直于立柱转角度 Max.vertical rotation of spindle box to column ±90° 10 主轴箱升降距离 Distance of spindle box movement 150mm 11 **大钻孔直径 Max.drilling diameter 16mm 12 **大力铣刀直径 Max.diameter of vertical milling cutter 20mm 13 **大力铣刀盘直径 Max.diameter of vertical milling face 63mm 14 主轴转速范围(4级)Range of spindle speed(4steps) 400-1640r.p.m 15 电机 Motor 220V,380V,50Hz,0.37;0.55KW,1400r.p.m 16 净重 Machine net weight 138Kg |
