产品类型 | 全新 |
---|---|
动力类型 | 电动 |
回转直径 | 400 |
加工长度 | 2000 |
加工精度 | 高精度 |
控制形式 | 人工 |
类型 | 普通车床 |
适用范围 | 通用型 |
外形尺寸 | 3650x1140x1750(mm) |
主电机功率 | 7.5 |
安装形式 | 落地式 |
是否库存 | 是 |
适用行业 | 通用 |
布局形式 | 卧式 |
主轴通孔直径 | 52/80 |
主轴转速级数 | 24 |
品牌 | 龙泽数控 |
加工直径 | 630 |
型号Model 技术参数Specifications | CA6240 | |
床身上工件直径Max.Swing over bed | 400mm | |
刀架上工件直径Max.Swing over carriage | 210mm | |
马鞍槽工件直径Max.Swing in gap | 630mm - | |
马鞍槽有效长度 Effective gap length | 210mm - | |
工件长度Max length of bed | 750mm/1000mm/1500mm/2000mm/2200mm/ 3000mm/4000mm | |
床身宽度Width of bed | 400mm | |
刀杆洁面Section of turming tool | 25×25mm | |
主轴 Spindle | 主轴转速范围 Spindle speeds | 10-1400rpm/16-1400rpm(24 steps) |
| 主轴内孔 Hole through spindle | 52mm |
| 主轴孔锥度 Spindle taper | 莫氏NO.6(MT6)(φ90 1:20) [φ113 1:20] |
进给 Feed | 进给数量Number of feeds | 64种(kinds)(for each) |
| 公制螺纹Range of metric threads(kinds) | (1-192mm)44种(44 kinds) |
| 英制螺纹Range of inch threads(kinds) | (2-24tpi)21种(21 kinds) |
| 模数螺纹Range of module threads(kinds) | 0.25-48(模数39种)(Module 39kinds) |
| 径节螺纹Range of pitch threads(kinds) | 1-96DP(37种)(37kinds) |
尾座 Taistock | 尾座主轴行程Max.tail stock spindle travel | 150mm |
| 尾座主轴直径Tail stock spindle diameter | 75mm |
| 尾座主轴孔锥度Taper of tail stock spindle center hole | 莫氏NO.5(MT5) |
主电机Main motor | 7.5KW(10HP_ | |
包装尺寸 Packing dimensins (L*W*H) | Overall dimensions for 750mm | 2550*1140*1750 |
| Overall dimensions for 1000mm | 2700*1140*1750 |
| Overall dimensions for 1500mm | 3200*1140*1750 |
| Overall dimensions for 2000mm | 3700*1140*1750 |
| Overall dimensions for 2200mm | 4030*1140*1750 |
| Overall dimensions for 3000mm | 4850*1140*1750 |
| Overall dimensions for 4000mm | 5800*1140*1750 |
重量 Weiight(kg) | Length | 毛重 净重 G.W N.W. |
| Weight for 7500mm | 2100 1990 |
| Weight for 1000mm | 2190 2070 |
| Weight for 1500mm | 2350 2220 |
| Weight for 2000mm | 2720 2570 |
| Weight for 2200mm | 2800 2600 |
| Weight for 3000mm | 3300 3200 |
| Weight for 4000mm | 3500 3400 |
