| 类型 | 摇臂铣床 |
|---|---|
| 重量 | 1300（kg） |
| 主电机功率 | 3（kw） |
| 主轴转速范围 | 60-4530（rpm） |
| 工作台尺寸 | 254x1270x82（mm） |
| 主轴锥孔锥度 | R8 |
| 控制形式 | 仿形 |
| 布局形式 | 立式 |
| 作用对象 | 五金 |
| 作用对象材质 | 金属 |
| 适用行业 | 通用 |
| 产品类型 | 全新 |
| 售后服务 | 一年保修 |
| 适用范围 | 通用 |
| 是否库存 | 是 |
| 品牌 | 上海钜凌 |
| 型号 | M3 |
I am grace from Shenzhen youxin Co.,ltd,glad to send you about our products,I think you have read our introduction,we are promissional trade company with more than 8 years experience on products ,and have got good reputation from our customers.
we enclosed detailed quotation according to your requirement for your reference ,It is my most pleasure to introduce the products,It should be much appreciate that you can add my
skype:gracewang8678
email:516375470@qq.com or
youxin.Grace888@yahoo.com
grace19351978@ho
msn:grace19351978@homy website iswww.chinayouxin.comandwww.szyouxin888.com
welcome to add me ,thank you
M3 | M4 | M5 | M6 | ||
工作台尺寸Table size | 254x1270x82 | 254x1320x82 | 280x1370x82 | ?305x1370x82 | |
行程Travel | 左右Longitude(X) | ▲730(自动)/850(手动) | ▲750(自动)/870（手动） | ▲750(自动)/870（手动） | ▲770(自动)/890（手动） |
前后（Y） | ▲4OO | ■430 | ■455 | ■460 | |
上下Vertical(Z) | ▲4OO | ■430 | ▲455 | ■460 | |
主轴行程Quill Travel? | 127 | 127 | 127 | 127 | |
滑轨行程Ram Travel | 550 | 550 | 610 | 620 | |
主轴Spindle | 速度Speed | 60-4530rpm(16速) | 80-5440rpm(16速) | 80-5440rpm(16速) | 80-5440rpm(16速) |
主轴进给率Feed | 0．004，0．008，0．15（mm/rev） | ||||
锥度Taper | R8 | R8 | R8 | NT40 | |
马力Motor | 3HP | 3HP | 5HP | 5HP | |
主轴端面至工作台面的**大距离Spindle nose to table | 45-455 | 45-445 | 50-480 | 60-540 | |
机床尺寸Machine dime | 1500x1680x2130 | 1500x1730x2200 | 1600x1780x2350 | 1700x1780x2400 | |
