特点: |
Widely useful, variable speed hobby lathe加工范围广,变速范围大V-way bed is hardened and precision ground V型床身和精密研磨Spindle is supported by precision bearing 使用精密轴承Power longitudinal feed allows threading纵向进给范围大Adjustable gibs for slideways 导轨经过淬火处理Casting iron change gears gets greater capacity铸铁改变齿轮得到更大的能力Higher rigidity in construction更高的刚性,建设Tailstock may be offset for turning tapers尾座可抵销车削锥度Equipped with emergency stop button配有紧急停止按钮Powerful motor电机功率大Tolerance test certificate, test flow chart included公差测试证书,测试包括流程图 |
SPECIFICATION:规格: |
Model No.型号 | WM250/WM250V | Distance between centers**大工件加工长度 | 550/750mm | Swing over bed床身上**大回转直径 | 250mm | Swing over cross slide刀架上**大回转直径 | 145mm | Width of bed床身宽度 | 135mm | Taper of spindle bore主轴锥孔 | MT4 | Spindle bore主轴孔径 | 26mm | Number of spindle speeds主轴转速级数 | 6 | Range of spindle speeds主轴转速范围 | 50~2500rpm | Range of longitudinal feeds纵向进给量范围 | 0.07-0.20mm/r | Range of inch threads车削英制螺纹 | 8-56T.PI | Range of metric threads公制螺纹范围 | 0.4-3.5mm | Top Slide travel小刀架**大行程 | 50mm 50毫米 | Cross slide travel後副滑板行程 | 115mm | Tailstock quill travel尾架套筒行程 | 70mm | Taper of tailstock quill尾架套筒锥度 | MT2 | Motor马达 | 750W | Packing size包装尺寸 | 1150/1350 x 560 x 570mm | Net weight净重 | 120/140kg |
|
STANDARD ACCESSORIES标准配件 | | OPTIonAL ACCESSORIES可选配件 |
|
Splash guard飞溅后卫 | 1个 | Chip tray芯片托盘 | 1个 | Toolbox&tools工具箱和工具 | 1套 | Speed counter高速计数器 | | | | | | | | | | | | | |
| | Four-jaw chuck四爪卡盘 | 1套 | Backplate背板 | 1个 | Follow rest按照休息 | 1个 | Steady rest稳态休息 | 1个 | Face plate面板 | 1个 | ER25 Collet chuck ER25夹头 | 1套 | Collet holdler科莱holdler | 1套 | Turning tools车刀 | 1套 | Quick change tool post快换刀架 | 1套 | Stand站 | 1套 |
| 备注:此机床电压选择 内销 220V/380V |
