材料 | 圆钢 |
---|---|
规格 | DLMX-5/M/K/Z |
扭矩 | 50 |
适用范围 | 铣床 |
品牌 | 冠海 |
型号 | DLMX |
·铣床配套、离合快速与制动; ·湿式润滑、无磨损、寿命长;
·铜质花键套、动作更灵敏; ·整体装配、无须调整、安装方便;
性能参数:Main Technical Data
规格 Size | 额定动力矩 Rated Dynamic | 额定静力矩 Rated Static | 接通时间 Engagement | 断开时间 Disengagement | 额定电压 Rated | 空载力矩 Drag |
DLMOM/K/Z-5 | Torque | Torque | Time | Time | Voltage | Torque |
N.m | N.m | ≤s | ≤s | DC V | ≤N.m | |
50 | 100 | 0.35 | 0.4 | 24 | 2.5 | |
说明:M为慢速、K为快速、Z为制动.Note:M:slow speed;K:quick speed;Z:brake |
