| 设备类型 | 卧式 |
|---|---|
| 品牌 | 西马特机床 |
| 型号 | CJK6150X1200 |
规格型号：CK6150×750/1000
技
术
参
数 | 项 目 | 参 数 | |
Max swing over bed | 床身上**大回转直径 | Φ500mm | |
Max turning dia. of workpiece | 拖板上**大回转直径 | Φ300mm | |
Max length of workpiece | **大工件长度 | 750/1000mm | |
Spindle speed | 主轴转速范围 | 150-1600rpm或三档变速 | |
Dia. of spindle bore | 主轴通孔直径 | Φ82mm | |
| 导轨宽度 | 400mm | |
Cone of spindle bore | 主轴头形式 | D-8 | |
Dia of tail stock sleeve | 尾座套筒直径 | 75mm | |
Store of tail stock sleeve | 尾座套筒行程 | 150mm | |
Bore taper of tail stock sleeve | 尾座**锥度 | MT5 | |
Rapid travel speed of X/Z axis | **移动速度X/Z轴 | 5/10m/min | |
Min unit to be set X/Z axis | **小设定单位X/Z轴 | 0.001/0.001mm | |
Tool position NOS of turret | 刀架工位数 | 4/6/8或排刀 | |
Main motor power | 主电机功率 | 7.5KW | |
Net weight | 机床净重 | 3200/3500kg | |
Dimension(L×W×H) | 外形尺寸(长×宽×高) | 2570/2970×1560×2110mm | |
