技术参数Specifications | CA6150 CA6150B CA6150C | CA6250 CA6250B CA6250C | |
床身工件直径Max. Swing over bed | 500mm | ||
刀架上工件直径Max. Swing over carriage | 300mm | ||
马鞍槽工件直径Max. swing in gap | -- | 720mm | |
马鞍槽有效长度Effective gap length | -- | 210mm | |
工件长度Max. length of work piece | 750mm/1000mm/1500mm/2000mm/2200mm/3000mm/4000mm | ||
床身宽度Width of bed | 400mm | ||
刀杆截面Section of turning tool | 25x25mm | ||
主轴 Spindle | 主轴转速范围Spindle speeds | 10-1400rpm/16-1400rpm（24steps） | |
主轴内孔Hole through spindle | 52mm（80mm）[105mm] | ||
主轴孔锥度Spindle taper | 莫式NO.6（MT6）（Φ90 1：20）[Φ113 1：20] | ||
进给 Feed | 进给数量Number of feeds | 64种（kinds）（for each） | |
公制螺纹Range of metric threads（kinds） | （1-192mm）44种（44kinds） | ||
英制螺纹Range of inch threads（kinds） | （2-24tpi）21种（21kinds） | ||
模数螺纹Range of module threads（kinds） | 0.25-48(模数39种)(Moduie39kinds) | ||
径节螺纹Range of pitch threads（kinds） | 1-96DP(37种)（37kinds） | ||
尾座 Tailstock | 尾座主轴行程Max. tail stock spindle travel | 150mm | |
尾座主轴直径Tail stock spindle diameter | 75mm | ||
尾座主轴孔锥度Taper of tail stock spindle center hole | 莫氏NO.5(MT5) | ||
主电机Main motor | 7.5KW(10HP) | ||
包装尺寸 Packing dimensions (L*W*Hmm) | Overall dimensions for750mm | 2550x1140x1750 | |
Overall dimensions for1000mm | 2700x1140x1750 | ||
Overall dimensions for1500mm | 3200x1140x1750 | ||
Overall dimensions for2000mm | 3700x1140x1750 | ||
Overall dimensions for2200mm | 4030x1140x1750 | ||
Overall dimensions for3000mm | 4850x1140x1750 | ||
Overall dimensions for4000mm | 5800x1140x1750 | ||
重量 Weight (kg) | Length | 毛重 净重 G.W N.W. | |
Weight for 750mm | 2170 2061 | ||
Weight for 1000mm | 2260 2140 | ||
Weight for 1500mm | 2420 2290 | ||
Weight for 2000mm | 2790 2640 | ||
Weight for 2200mm | 2940 2790 | ||
Weight for 3000mm | 3450 3300 | ||
Weight for 4000mm | 3750 3600 | ||
